Now, how to use this wheelchair ramp slope calculator?Ĭhoose the ramp's application. Use it as either an ADA ramp slope calculator to meet the government's standards, or as a tool to calculate the ramp explicitly tailored to your needs. If you're wondering how to build a ramp, our ramp calculator will be a great help in its design and construction. taking into account weather conditions if it's an outdoor ramp ( proper drainage).edge protection and handrail extensions,.the ramp should be made out of appropriate material to prevent sliding and slipping,.the cross slope (camber) of the ramps cannot exceed 1:50,.You will find more details in paragraph 4.8.5 of the ADA Ramp Document Then the handrails are needed on both sides to comply with ADA standards. You need to provide enough space for maneuvers: if the ramp construction changes direction (a 90 degree turn), then the minimum landing size is 60"圆0":ĭon't forget to add even more space for switchback ramps.Minimum landing length is 60 in (1525 mm), and the landing's width should be at least as wide as the ramp's run.The following landing features are essential: Don't forget to take into account the mounting of handrails when designing a ramp.Įvery ramp should have level landings at the top and bottom of each section - especially if your ramp has multiple sections (turns). The minimum clear width of a ramp is 36 in (91.5 cm). When constructing a ramp, be it for your home, public space or temporary use, you need to think about a few things other than a ramp slope and rise: Remember that the ADA prohibits slopes steeper than 1:8. However, stricter restrictions on the maximum rise apply: Slope If existing sites, buildings, and facilities have space limitations, steeper ADA ramp slopes may be permitted. These three ADA ramp slope values are preset in our ramp calculator. In each case, the maximum rise allowed is 30 inches (760 mm). 1:20 is the minimum slope - below that value it's not considered a ramp (thus e.g., handrails are not needed).1:12 is the maximum slope of a ramp for new constructions.Apart from that information, what exactly does the guideline say? In this paragraph, we'll take a closer look at ADA ramp slopes.Īccording to the ADA standards, the least steep slope shall be used for any ramp. As well as including many different accessibility standards, it contains guidelines for ramp construction. The 2010 ADA Standards (Americans with Disabilities Act) set out some minimum requirements for new public facilities. Inverse cosine, if you know the run and the hypotenuse: Inverse sin, if you know the rise and the hypotenuse:
In this wheelchair ramp slope calculator, ramp length is the hypotenuse, but for stairs it will be the stringer length, and for roofing - the rafter length.Īlternatively, you can find the slope using inverse functions: In this case, you can calculate the run directly from Pythagorean formula: However, you might know the rise and the hypotenuse of the right triangle the ramp forms. Well, that depends what information you have - if you know the rise and run (the easiest case) then you can use the formulas mentioned above. Slope as fraction, percentage and in degreesĪfter that intro on slope units, let's come back to the heart of the matter: how do you calculate the slope of a ramp? It's calculated from the tangent of the inclination angle: Be careful - a 100% slope is not an equivalent to 90 degrees, but to 45 degrees. Giving the grade (slope) as a percentage is the most common way of describing slopes in the US and in Europe. To calculate the slope's angle, use the inverse tangent: This angle is commonly expressed in degrees, though other angle units are possible. It's the angle between ramp and run (or, in other words, angle of inclination to the horizontal). You can finds the missing term of any ratio with our ratios calculator! for example, with a 1:12 ratio, for each unit of vertical rise, you need to have 12 units of horizontal run, so 1 inch of rise means that 12 inches (1 foot) of horizontal space is needed. It can be expressed in a few different notations: 1:8, 1/8, 1 in 8, e.g. This is the ratio of one part rise to the appropriate part of the run. You can express slope in many ways, but let's focus on the three most popular forms: Before we show you how to calculate the slope of a ramp, we first need to explain slope unit convention.
